BMW M20B27 Race Series Pistons
BMW M20B27 Race Series Pistons - Image 2
BMW M20B27 Race Series Pistons - Image 3
BMW M20B27 Race Series Pistons - Image 4
BMW M20B27 Race Series Pistons - Image 5
BMW M20B27 Race Series Pistons - Image 6
BMW M20B27 Race Series Pistons - Image 7

The picture may vary from the real product.

BMW M20B27 Race Series Pistons

1.200,00€ (exc. Vat)

Race Series forged pistons for the BMW M20B27. Designed and made in-house at DP Engine Parts, Greece.

Optional extras

SKU: N/A Category: Tags: , ,
🌀 Turbo

Technical data — M20B27

Displacement2693cc
Production Years1982-1988
Block MaterialCast Iron
Cylinder CoatingNone
Bore Spacing (mm)91.0
Bore (mm)84.00
Stroke (mm)81.00
Rod Length (mm)135
Wrist Pin Diameter (mm)22
Rod Big End Bore (mm)48
Rod Big End Thickness (mm)21.89
Rod Small End Thickness (mm)21.89
Cylinders6
CH (mm)31.2
Compression Ratio9.8 (Euro)
Bore84, 84.5, 85
CH (Compression Height)31.2
CR (Compression Ratio)8.5
Pin Size (Ø)22

Race Series forged pistons for the BMW M20B27 (turbo). Designed and manufactured in-house at DP Engine Parts, Greece, with full CAD/CAM control from design to finished part.

  • Piston pin: 22 mm

Pair them with our BMW M20B27 connecting rods for a complete, matched set. Worldwide shipping. Contact us for custom specifications.

Series

Performance, Race, Pro
Pin Diameter

22
