Volvo B230 8V Race Series Rods - DP Engine Parts
Volvo B230 8V Race Series Rods - DP Engine Parts

The picture may vary from the real product.

Volvo B230 8V Race Series Rods

920,00€ (exc. Vat)

Race Series connecting rods for the Volvo B230 8V. Designed and made in-house at DP Engine Parts, Greece.

Optional extras

SKU: N/A Category: Tags: , ,

Technical data — B230 8V

Displacement2316cc
Production Years1985–1998
Block MaterialCast Iron
Cylinder CoatingNone
Bore (mm)96.00
Stroke (mm)80.00
Rod Length (mm)155
Wrist Pin Diameter (mm)23
Rod Big End Bore (mm)52mm
Rod Big End Thickness (mm)29.5mm
Cylinders4
CH (mm)36.5
Rod Length155
Pin Size (Ø)23
Rod DesignA-Beam
Big End Ø52
Big End Thickness29.5
Small End Thickness29.5

Race Series connecting rods for the Volvo B230 8V. Designed and manufactured in-house at DP Engine Parts, Greece, with full CAD/CAM control from design to finished part.

  • Piston pin: 23 mm
  • Rod length: 155 mm
  • Beam design: A–beam

Pair them with our Volvo B230 8V pistons for a complete, matched set. Worldwide shipping. Contact us for custom specifications.

Series

Performance, Race, Pro, Aluminum Pro
Design

A-Beam
