BMW M20B30 Turbo Race Series Pistons

Price range: 1.200,00€ through 1.620,00€ (exc. Vat)

Race Series forged pistons for the BMW M20B30 Turbo. Designed and made in-house at DP Engine Parts, Greece.

Optional extras

SKU: N/A Categories: , Tags: , ,
🌀 Turbo

Technical data — M20B30

Block MaterialCast Iron
Cylinder CoatingNone
Bore Spacing (mm)91.0
Bore (mm)84
Stroke (mm)89.6
Rod Length (mm)135
Wrist Pin Diameter (mm)22
Rod Big End Bore (mm)48
Rod Big End Thickness (mm)21.89
Rod Small End Thickness (mm)21.89
Cylinders6
CH (mm)26.9
Compression Ratio9.0-9.2 (no OEM code)
Bore84.5, 85, 85.5, 86
CH (Compression Height)26.9
CR (Compression Ratio)9.0, 9.2
Pin Size (Ø)22
Pin Part Number555PP22D10
Pin Length55.5
Ring Thickness — 1st (mm)1.00
Ring Thickness — 2nd (mm)1.20
Ring Thickness — 3rd (mm)2.80

Race Series forged pistons for the BMW M20B30 Turbo (turbo). Designed and manufactured in-house at DP Engine Parts, Greece, with full CAD/CAM control from design to finished part.

  • Piston pin: 22 mm

Pair them with our BMW M20B30 Turbo connecting rods for a complete, matched set. Worldwide shipping. Contact us for custom specifications.

Weight 7 kg
Series

Performance, Race, Pro

Pin Diameter

22
